Stewarts Bourden Tube Stainelss Steel Pressure Gauge - 63mm Dial - Bottom Entry
Stewarts Bourden Tube Stainelss Steel Pressure Gauge - 63mm Dial - Bottom Entry - -100 / 0 kPa: 1/4" BSPT Connection bottom entry / None is backordered and will ship as soon as it is back in stock.
Description
Description
The Stewarts Bourden Tube Stainelss Steel Heavy Duty Pressure Gauge is liquid fillable ideal for the oil, chemical, food and beverage industries.
The Stewarts Bourden Tube Stainless Steel Heavy Duty Pressure Gauge features a robust AISI 304 stainless steel weatherproof case and bezel, ensuring durability in demanding environments. Its aluminium dial and black-finished aluminium pointer provide clear readability, protected by a sheet glass window. The gauge includes a fully welded AISI 316 stainless steel socket and element for enhanced corrosion resistance. With a precision stainless steel movement, it offers accuracy of 1.6% F.S. for 63mm and 1% F.S. for 100mm and 150mm dial sizes. Suitable for temperatures from -20°C to +60°C and an overrange capacity up to 130%, it delivers reliable performance with an IP rating up to IP67.
SPECIFICATIONS
| MODEL | 632 |
| NOMINAL SIZE | 63mm |
| SCALE RANGE | -100 ... 60,000KpA |
| ACCURACY | 1.6% F.S. |
| PROCESS CONNECTION | 1/4" BSP TAPER |
| CONNECTION LOCATION | LOWER MOUNT |
| WINDOW | GLASS |
| TEMPERATURE RANGE | -20°C TO +60°C |
| CASE MATERIAL | STAINLESS STEEL WEATHERPROOF |
